Electrical Data
Current

• Max. input current: 16A / 16A
• Max. short circuit current: 20A / 20A;
• Max. output current: 27.3 A / 26.1 A;
• Rated grid output current: 27.3 A / 26.1 A;

Wattage

• Max. usable PV input power: 9.6kW;
• Max. charge / discharge power: 6kW;
• Rated output power AC: 6kW

Voltage

• Max. PV Input DC Voltage: 500V;
• MPPT Range: 90~435V;
• Rated PV Input DC Voltage: 330V;
• Start-up Voltage: 90V;

Frequency
Rated grid frequency: 50 Hz / 60 Hz
Power Factor
>0.99 (0.8 leading - 0.8 lagging)
Capabilities
IP Rating
IP66
Working conditions
`-40 ~ +60°C
Dimensions
Size
335 x 560 x 227 mm
Product Data
Order code
12223
Product code
S6-EH1P6K-L-PLUS
Items per pack
1
Item Weight
21.6 kg
