Electrical Data
Current

• Max. input current: 40A / 40A
• Max. short circuit current: 50A / 50A;
• Max. output current: 22.8A / 21.7A;
• Rated grid output current: 22.8A / 21.7A;

Wattage

• Max. usable PV input power: 24kW;
• Rated output power AC: 15kW

Voltage

• Max. PV Input DC Voltage: 1000V;
• MPPT Range: 200~850V;
• Rated PV Input DC Voltage: 550V;
• Start-up Voltage: 160V;

Frequency
Rated grid frequency: 50 Hz / 60 Hz
Power Factor
>0.99 (0.8 leading - 0.8 lagging)
Capabilities
IP Rating
IP66
Working conditions
`-40 ~ +60°C
Dimensions
Size
430 × 660 × 295 mm
Product Data
Order code
12229
Product code
S6-EH3P15K02-NV-YD-L
Items per pack
1
Item Weight
42 kg
